A washer lid that will not stay open or close properly often points to a worn hinge. This quick repair helps restore smooth movement and keeps your washer working the way it should.
What the Lid Hinge Does and Why It Fails
The lid hinge is a small metal part that supports the washer lid as it opens and closes. It keeps the lid aligned and helps it stay in position during use.
Over time, the hinge wears down from repeated movement. It can bend, loosen, or lose tension. When that happens, the lid may sag, feel unstable, or fail to close fully. This can interrupt wash cycles, especially on models that rely on a secure lid position to operate.
Common Signs of a Worn Lid Hinge
Spotting the issue early helps avoid bigger problems with your washer.
- Lid does not stay open on its own
- Lid feels loose or uneven when opening
- Lid does not close flush with the top
- Washer will not start due to lid position
- Squeaking or grinding sound near the hinge
- Lid drops quickly instead of holding position
- Visible gap between lid and washer top
- Lid shifts to one side when closing
- Extra force needed to open or close the lid
What You Need Before You Start
Gather your tools and parts so the process goes smoothly.
- Replacement lid hinge WP8563965 compatible with your washer
- 1/4 inch nut driver
- Flathead screwdriver
- Torx 15 screwdriver
- Strap with hooks
Safety Tips Before Starting
Take a few minutes to set up safely before working on your washer.
- Unplug the washer from the power source before starting
- Let the machine cool down if it was recently used
- Turn off the water supply and keep towels nearby
- Work in a bright and clear space
- Keep children and pets away from the area
- Keep hands dry when handling internal parts
- Wear gloves to protect against sharp edges
- Avoid touching exposed wires directly
- Take photos before disconnecting any parts to help with reassembly
Why This Repair Is Worth Doing
A faulty hinge may seem minor, but it can stop your washer from running properly. Fixing it early keeps your laundry routine on track and prevents extra strain on other parts. This repair is simple, affordable, and can be done in under an hour with basic tools.
How to Replace Whirlpool/KitchenAid/Maytag Washer Lid Hinge
Follow these steps to remove the old hinge and install a new one so your washer lid works properly.
Remove the Old Lid Hinge
- Unplug the washer from the power outlet
- Open the washer lid to access the hinge area
- Use a Torx 15 screwdriver to loosen the two hinge screws
- Locate one screw at the top of the hinge and one at the bottom
- Use a small flathead screwdriver to pry the screws out
- Lift the left side of the washer lid slightly to release the hinge
- Pull the old hinge straight out from the washer casing
Install the New Lid Hinge
- Insert the new hinge into the opening on the left side
- Align the hinge holes with the holes in the washer casing
- Adjust the hinge until it sits in place
- Insert one Torx 15 screw into the bottom hole
- Insert the second screw into the top hole while the bottom screw is still loose
- Tighten both screws to secure the hinge
Test the Washer Lid
- Close and open the washer lid to check movement
- Plug the washer back into the power outlet
- Run a short test cycle to confirm proper operation
Mistakes to Avoid During Lid Hinge Replacement
Small mistakes can lead to extra work or damage. Keep these in mind while working.
- Skipping the unplug step before starting
- Using the wrong tools for hinge screws
- Forcing the hinge out instead of loosening it properly
- Misaligning the new hinge during installation
- Overtightening screws which can strip threads
- Forgetting how parts were positioned before removal
- Ignoring signs of damage on surrounding parts
- Dropping screws inside the washer body
- Rushing through the process without checking alignment
What’s Next?
A washer lid that works the way it should makes everyday laundry easier and less frustrating. A new hinge brings back smooth movement, keeps the lid stable, and helps your washer run without interruptions. This small fix goes a long way in keeping your machine reliable.
Take a moment to check the lid after a few uses and listen for any unusual sounds. Everything should feel steady and aligned. With the new hinge in place, your washer is ready to handle loads without the hassle of a loose or misaligned lid.
