If your Whirlpool, KitchenAid, or Maytag dishwasher isn’t functioning properly, the electronic control board might need to be replaced. This essential component controls the appliance’s functions, and a DIY replacement can save both time and money. Here’s a straightforward guide to help you complete the task safely and efficiently.
Signs Your Control Board May Need Replacement
The electronic control board acts as the operational hub of your dishwasher. If features stop working or the dishwasher ceases operation altogether, it might be time to replace this part.
Tools and Materials You’ll Need
- Torx 15 screwdriver: To remove control panel screws.
- Flat blade screwdriver: For releasing tabs and disconnecting wiring.
- Replacement part: Electronic control board WPW10285179.
Safety Precautions
Safety is paramount when working on appliances. Follow these guidelines to complete a safe and successful repair:
- Disconnect Power: Always unplug the dishwasher or turn off its circuit breaker to eliminate electrical risks.
- Turn Off Water Supply: Shut off the water supply to avoid leaks.
- Prepare Your Workspace: Use towels or a protective mat to protect surrounding surfaces.
- Let It Cool: Wait for the appliance to cool down completely if it is recently used.
- Keep the Area Clear: Work in a well-lit, clutter-free space. Keep pets and children away.
- Stay Dry: Make sure your hands and the work area are dry before handling any internal components.
- Use the Manual: Refer to the user manual for specific installation details or safety instructions.
- Handle Parts Carefully: Use gentle force to avoid damaging components or causing injury.
- Wear Gloves: Insulated work gloves protect your hands from sharp edges and debris.
- Avoid Direct Contact with Wires: Use insulated tools to handle wires and prevent electrical shock.
How to Replace a Dishwasher Control Board
Removing the Control Panel
- Open the dishwasher door and locate the control panel along the top edge inside the door.
- Use a Torx 15 screwdriver to remove the six screws securing the control panel assembly. Set the screws aside.
- Gently pull the control panel away from the door, leaving it partially connected by wiring.
- Locate the cover panel at the bottom of the control panel, secured by four plastic tabs.
- Use a flat-blade screwdriver to pry outward on each tab and release the cover panel. Set it aside.
Removing the Old Control Board
- Find the bracket near the door latch mechanism. It has locking tabs on both sides.
- Use a flat-blade screwdriver to pry open the tabs and remove the bracket. Set it aside.
- Locate the thin flex cable, which is connected to the control board, near the center of the control panel. Disconnect the flex cable carefully.
- Slide the control board to the side and lift it up while using the flat-blade screwdriver to release the lock tabs near the flex cable connection.
- Fully detach the control panel from the door and set it aside.
- Flip the control board over to access the wire connections.
- Disconnect the wire bundle plugs by releasing the locking tabs with a flat-blade screwdriver. Pull firmly but gently to detach the plugs.
- Note the wire colors and labels or take pictures to reference later.
- Remove the old control board and discard or recycle it appropriately.
Installing the New Control Board
- Position the new control board so the labeled plug ports align with the old board.
- Match the wire colors and push each wire plug into its corresponding port until it clicks and locks into place. Refer to your notes or pictures as needed.
- Attach the thermal fuse securely to its bracket on the new control board.
- Place the new control board back into position on the control panel.
- Reconnect the thin flex cable by firmly pushing it into its socket.
- Reattach the control cover panel securely into place.
Reassembling the Dishwasher
- Snap the door latch mechanism back into place.
- Press the control panel firmly against the inner door panel.
- Insert the six Torx 15 screws into their holes and tighten them with the screwdriver.
- Close the dishwasher door.
- Reconnect the power and water supply lines.
- Run an empty test cycle to confirm the dishwasher is working correctly.
Also Read: Signs of a Faulty Frigidaire or Electrolux Dishwasher Control Board and How to Replace It
What Causes Control Board Failure?
Several factors can contribute to the control board malfunctioning:
- Power Surges: Electrical surges can damage the control board’s circuits, causing it to fail.
- Moisture Exposure: Dishwashers operate in a humid environment, and leaks or condensation can impact the board over time.
- General Wear and Tear: As the dishwasher ages, the control board may wear out due to repeated use.
Maintenance Tips to Avoid Future Problems
To keep your dishwasher running smoothly and prevent control board failure:
- Use a Surge Protector: Install a surge protector for your appliances to protect against sudden voltage spikes.
- Check for Leaks: Regularly inspect the dishwasher for leaks or moisture buildup that might damage internal components.
- Clean Filters and Seals: Clogged filters can affect performance, while damaged seals may allow water to enter sensitive areas.
- Run Regular Cycles: Regularly use the dishwasher to keep components functional and prevent the buildup of debris or rust.
Replacing your dishwasher’s control board might seem like a hassle at first, but with this guide, it’s totally doable. Whether you’re dealing with a Whirlpool, KitchenAid, or Maytag, a little effort can save you time and money and the headache of waiting for a repair service.
To keep your dishwasher running smoothly, check for leaks, protect it with a surge protector, and clean it regularly. Small steps like these can help you avoid bigger issues down the line.
