Replacing the igniter kit and bracket in a Whirlpool gas dryer is a straightforward task that can help restore your appliance’s functionality when these components wear out. The igniter plays a critical role in heating the dryer by sparking the gas. Here’s a step-by-step guide to help you complete this DIY repair.
Common Signs of a Faulty Igniter
A faulty igniter can cause your dryer to stop heating properly, which may leave clothes damp or completely wet after a cycle. Here are some common symptoms indicating the igniter may need replacement:
- No Heat: The dryer runs, but no heat is generated during the cycle.
- Unusual Clicking or Humming Sounds: These sounds may indicate the igniter is attempting to spark but failing.
- Error Codes: Some dryers display error codes related to heating issues.
- Burnt Odor: A burnt smell could suggest the igniter is malfunctioning or damaged.
Tools and Materials Needed
- Screwdriver: A Phillips or flat-head screwdriver, depending on your dryer’s screws.
- Putty knife: For releasing locking tabs and opening panels without damage.
- Socket set: For bolts or screws requiring specific sizes.
- Pliers: To handle small parts with precision.
- 5/16-inch nut driver
- Flashlight
- Safety gloves: To protect your hands from sharp edges.
Safety Guidelines
Before beginning any repair, prioritize safety by following these steps:
- Disconnect Power: Unplug the dryer or turn off the circuit breaker to eliminate the risk of electric shock.
- Prevent Carbon Monoxide Hazards: Install carbon monoxide detectors on each level of your home. If you experience symptoms such as headaches, nausea, or dizziness, move to fresh air immediately and seek medical assistance.
- Cool Down the Dryer: Wait for the appliance to cool completely if it has been recently used.
- Keep Your Workspace Safe: Work in a well-lit, clutter-free area. Keep children and pets away from the repair zone.
- Avoid Wet Conditions: Make sure your hands and the work area are dry to prevent electrical hazards.
- Consult the Manual: Refer to your dryer’s user manual for specific safety and installation instructions.
- Handle Components Carefully: Avoid using excessive force, which could damage parts or cause injury.
- Wear Protective Gear: Use insulated gloves to shield your hands and safety glasses if dust or debris is present.
How to Replace the Gas Whirlpool Dryer Igniter
Preparation
- Unplug the dryer or turn off the circuit breakers to eliminate the risk of electrocution.
Access the Dryer Components
- Lift the lint screen cover and remove the two screws. If the lint screen has a built-in cover, pull it out before removing the screws.
- Use a putty knife to press and release the locking tabs located about two inches from each corner of the top panel.
- Press above the tabs to release the top panel.
- Use a screwdriver to disconnect the clip holding the door switch wiring harness.
- Remove the two 5/16-inch hex-head screws securing the front panel.
- Lift the front panel and rest it on the clips at the base of the machine.
- For dryers with two panels, use a small screwdriver or putty knife to pop off the smaller access panel.
- Remove the door springs if they are present.
- Loosen the screws on the bottom of the main panel.
Remove the Drum
- Press the pulley towards the outside of the dryer to release tension and remove the belt from the pulley.
- Grab the belt and support the drum while pulling it out from the front of the dryer.
Replace the Igniter
- Locate the igniter assembly inside the dryer.
- Remove the 5/16-inch screw holding the igniter assembly.
- Carefully pull out the old igniter, avoiding damage to the fragile gray part.
- Use a small flat-head screwdriver to disconnect the wire harness from the igniter.
- If necessary, replace the old igniter bracket by loosening it with a 5/16-inch socket and attaching the new igniter to the bracket with the same screw.
- Insert the new igniter into the burner tube carefully and secure it with the mounting screw.
- Reattach the wire harness to the new igniter using a small flat-head screwdriver.
Reassemble the Dryer
- Reinsert the drum into the dryer, making sure it rests properly on the roller wheels without pinching the felt.
- Reinstall the belt by creating a loop and pulling it over the motor pulley.
- Align the front panel with the small teeth on the dryer and push it down onto them.
- Lift and align the drum with the front seal, wiggling the drum if needed.
- Secure the front panel with the 5/16-inch screws.
- Reconnect the door switch wiring harness and reattach any additional panels.
- Align the screw holes for the lint screen and secure it in place.
Test the Dryer
- Plug the dryer back into the power source.
- Turn on the dryer and run a small test cycle to confirm proper operation.
How to Maintain the New Igniter
After replacing the igniter, regular maintenance can help extend its lifespan and keep your dryer functioning properly. Here are a few tips:
- Clean the Lint Trap Regularly: A clogged lint trap can reduce airflow and place extra strain on the igniter and other components.
- Inspect the Vent System: Check for blockages or buildup in the dryer vent to promote proper airflow and efficient heating.
- Avoid Overloading: Overloading the dryer can lead to excessive wear on the heating system, including the igniter.
- Schedule Routine Checks: Periodically inspect the igniter and related components to spot potential issues early.
Replacing the igniter in your Whirlpool gas dryer might seem like a job for a professional, but with a little time and effort, it’s something you can handle yourself. After all, why let a small part like the igniter stop you from enjoying freshly dried laundry?
Doing this repair yourself means saving money, skipping the wait for a technician, and feeling proud of fixing it on your own. With some simple maintenance tips, you can also keep your dryer running smoothly for a long time.
Don’t let damp clothes pile up. Grab your tools, roll up your sleeves, and get your dryer back to work.
