If your Whirlpool dryer is making loud rumbling noises or taking longer than usual to dry clothes, the problem might be a faulty blower wheel.
The blower wheel is essential in pushing air through the dryer drum and vent system. Over time, it can wear out or get clogged with lint, which may lead to excessive noise or reduced efficiency.
Before replacing the blower wheel, inspect and clean any lint buildup that could be causing the issue. If the wheel is damaged or your dryer’s performance hasn’t improved after cleaning, a replacement is likely necessary.
Common Signs Your Blower Wheel Needs Replacement
If you’re not sure whether the blower wheel is the problem, look out for these signs:
- Unusual Noises: Loud rumbling, rattling, or squealing sounds during operation.
- Reduced Airflow: Minimal air coming out of the vent despite the dryer running.
- Longer Drying Times: Clothes take significantly longer to dry, even in high settings.
- Burning Smell: A burning or overheating smell can indicate restricted airflow.
- Excessive Lint Accumulation: Large amounts of lint collect around the drum or vent.
- Uneven Drying: Clothes come out damp in some areas and dry in others.
- Visible Damage: Cracks, warping, or debris stuck in the blower wheel when inspected.
Tools and Supplies Needed
- Phillips head screwdriver
- 1/4-inch nut driver
- Needle-nose pliers
- Socket wrench with 1/2-inch extension
- Adjustable wrench
- Replacement blower wheel (Whirlpool part WP697772) – Verify compatibility with your specific dryer model.
Prioritize Safety
Always follow these safety precautions when working on your dryer:
- Power Down the Appliance: Unplug the dryer or switch off its circuit breaker before beginning any work. This eliminates the risk of electric shock.
- Let the Dryer Cool: If it has been recently used, allow sufficient time for it to cool down.
- Work in a Safe Environment: Use a well-lit, uncluttered space, and keep children and pets away.
- Read the Manual: Check your appliance manual for specific instructions related to the replacement.
- Handle Parts with Care: Avoid using excessive force, which can damage the dryer or cause injury.
- Wear Proper Gear: Insulated gloves protect against sharp edges, and safety glasses or a dust mask can help if you’re dealing with debris or lint.
- Avoid Exposed Wires: Use non-conductive tools or insulated gloves when working around wires.
How to Replace a Whirlpool Dryer Blower Wheel
Here’s a simple guide to help you swap out your dryer’s blower wheel.
Disassemble the Dryer
- Turn off the dryer and disconnect it from the power supply.
- Use a 1/4-inch nut driver to unscrew the two screws at the back of the top panel.
- Slide the top panel back and lift it off.
- Remove the screws in the upper corners of the control panel.
- Detach the wire plugs and slide out the control panel.
- Open the dryer door and remove the lint screen.
- Remove the Phillips screws along the inside of the front panel.
- Close the door, tilt the dryer back, and place a wood block under the front legs for support.
- Use a 1/4-inch nut driver to remove the screws from the front panel.
- Unplug the door switch wire and remove the front panel.
- Remove the duct retaining bracket and detach the front bulkhead.
- Reach into the drum belt area and lift the idler arm to release belt tension.
- Slide the belt off the pulleys and carefully remove the drum from the dryer.
Remove the Old Blower Wheel
- Use a 1/4-inch nut driver to remove the single screw securing the blower wheel cover.
- Take off the blower wheel cover.
- Insert an adjustable wrench on the flat side of the motor shaft and wedge it against the blower housing.
- Insert a socket wrench with a 1/2-inch extension into the center of the wheel and turn clockwise to loosen.
- Unscrew the blower wheel by hand and remove it from the shaft.
- Discard the old blower wheel.
Install the New Blower Wheel
- Thread the new blower wheel clockwise onto the motor shaft by hand until it is tight.
- Wedge the adjustable wrench against the blower housing to hold the shaft steady.
- Use the socket wrench to tighten the new blower wheel onto the shaft.
- Replace the blower wheel cover by inserting the tab into the slot and securing it with the screw using a 1/4-inch nut driver.
Reassemble the Dryer
- Position the drum on the support rollers and slide it back into the cabinet.
- Loop the belt around the idler pulley and motor drive pulley.
- Turn the drum manually to check the belt tension.
- Reattach the front bulkhead and secure it with a 1/4-inch nut driver.
- Reconnect the wire plug to the front bulkhead.
- Replace the duct retaining bracket and top brace.
- Screw in the front panel using the 1/4-inch nut driver.
- Reattach the control panel and secure it with screws.
- Slide the top panel into place and secure it with screws.
- Reconnect the dryer to the power supply and test for proper operation.
Key Benefits of Replacing a Faulty Blower Wheel
Replacing a damaged blower wheel has several advantages, including:
- Improved Efficiency: Restores the dryer’s airflow for faster drying times.
- Quieter Operation: Eliminates the rumbling or rattling noises caused by a worn-out blower wheel.
- Extended Appliance Life: Prevents additional strain on the motor and other components.
- Energy Savings: Reduces drying time, leading to lower energy consumption.
- Consistent Performance: Provides reliable operation for all types of loads.
- Safer Operation: Reduces the risk of overheating caused by restricted airflow.
- Better Maintenance: Encourages regular inspections and cleaning of internal components.
A bad blower wheel can mess up your Whirlpool dryer and turn laundry day into a headache. If your dryer sounds like heavy machinery or struggles to dry clothes, the blower wheel could be the issue. Fixing this might sound tricky, but with the right tools, a clear guide, and some basic safety steps, it’s totally doable. With a little effort and the right approach, you can fix it and get back to a quieter, faster laundry experience in no time.
