The motor in your dryer drives the tumbling action essential for drying your clothes. Over time, wear and tear or unexpected damage can cause it to fail. If the drum stops spinning, the dryer won’t start, or you hear strange noises coming from the motor, it may need to be replaced.
Here’s how you can replace the motor in your Speed Queen dryer using basic tools and careful preparation.
Common Signs of a Failing Motor
A failing motor can display several symptoms. Recognizing these can help you address the problem early:
- The dryer drum does not spin despite the power being on.
- The dryer makes humming, buzzing, or grinding noises during operation.
- The dryer shuts off during a cycle due to overheating.
- The motor emits a burning smell when the dryer is in use.
- The dryer takes significantly longer to complete a cycle or fails to start altogether.
What You’ll Need
- Replacement Motor (confirm compatibility with your specific dryer model)
- 1/4-Inch Nut Driver
- Adjustable Wrench
Safety Precautions
Working on any appliance requires a focus on safety. Follow these precautions to protect yourself and your equipment:
- Disconnect Power: Always unplug the dryer or switch off the circuit breaker before starting. This prevents the risk of electric shock.
- Allow Cooling Time: If the appliance was recently used, let it cool completely before beginning any work.
- Work Slowly and Carefully: Precision is key; rushing can lead to accidents or errors.
- Good Lighting is Essential: Proper visibility helps you locate and handle components correctly.
- Clear the Workspace: Keep the area around the dryer free of clutter. Keep children and pets away.
- Dry Hands and Workspace: Never work on the dryer with wet hands or in a damp environment.
- Refer to the User Manual: Check for any model-specific instructions regarding installation or safety.
- Handle Components Gently: Use care when removing or attaching parts to avoid unnecessary damage.
- Wear Protective Gloves: Insulated work gloves can shield your hands from sharp edges and debris.
- Avoid Direct Contact with Wires: Use non-conductive tools or wear insulating gloves when working near exposed wires.
- Document Connections: Take photos or make notes of wiring and connections before disconnecting them for easier reassembly.
How to Replace the Motor in a Speed Queen Dryer
Access the Old Motor
- Unplug the dryer from the power outlet.
- Use a 1/4-inch nut driver to remove the two screws at the bottom of the front access panel.
- Remove the two screws, one on each bottom corner, on the upper panel of the front of the dryer.
- Rotate the bottom panel out to about 45 degrees, then lower it and set it aside.
- Take a picture of the door switch wiring for reference.
- Disconnect the door switch wires.
- Use a 1/4-inch nut driver to remove the four screws holding the front bulkhead to the frame.
- Lift the bulkhead slightly to clear the tabs, then pull it down and out. Set it aside.
- Reach back and remove the belt from the motor pulley.
- Use the belt to pull the drum out, then set the drum aside.
- Remove the screws securing the blower wheel housing cover and take off the cover.
- Secure the motor pulley with an adjustable wrench, then rotate the blower wheel counterclockwise to remove it.
- Use a 1/4-inch nut driver to press down and pry away the motor mounting clips.
- Lift the old motor out and pull it away from the blower housing.
Install the New Motor
- Angle the new motor into the blower housing and onto the motor mount.
- Install the motor mounting clips and reconnect the wires.
- Place the blower wheel back onto the motor and rotate it clockwise to secure it.
Reassemble the Dryer
- Replace the blower wheel housing cover and secure it with screws.
- Reinstall the drum and belt, making sure the drum rests properly on the back rollers.
- Reattach the front bulkhead and secure it with the screws.
- Reconnect the door switch wires.
- Angle the top front panel back into place, allowing the top brackets to hook into the top panel.
- Rotate the front panel into position and secure it with screws.
- Reinstall the bottom front panel and secure it with the remaining screws.
- Plug the dryer back in.
- Test the dryer to confirm the new motor is functioning correctly.
Post-Repair Testing
After completing the repair, verify that the dryer operates correctly. Here’s what to check during a test cycle:
- Drum Rotation: The drum should rotate smoothly without resistance or unusual noises.
- Noise Levels: The motor should operate quietly, without humming or grinding.
- Cycle Completion: The dryer should complete a full cycle without interruptions or overheating.
- Dryer Performance: Clothes should tumble effectively and dry within the expected timeframe.
- Odor Check: Ensure no burning smells occur during operation.
If the dryer functions as expected, the repair was successful. If issues remain, double-check the installation process and wiring connections.
