If the left or right rear element on your Samsung electric range is not heating up, it may be time to replace it. Fortunately, you do not need to call a repair technician right away. With a few tools and some patience, you can test and replace the faulty element yourself, saving both time and money.
Common Symptoms of a Faulty Element
Knowing when a surface element is malfunctioning can help you decide when to investigate further. Watch for these signs:
- The element does not heat up at all, even when the control knob is turned on
- The element heats inconsistently or shuts off while in use
- There is visible damage such as blistering, cracks, or discoloration
- The cooktop trips a circuit breaker during use
- A burning smell or smoke appears when the element is turned on
- The element glows, but food still takes longer to cook than usual
- You hear popping or buzzing noises from the area near the faulty element
What You Will Need
- Phillips head screwdriver
- Multimeter
Safety First
Before getting started, it is important to work safely. Keep the following safety tips in mind:
- Power Off: Unplug the range or switch off the circuit breaker before beginning. This eliminates the risk of electric shock.
- Let It Cool: If the stove has been used recently, wait until it is completely cool.
- Work Carefully: Take your time. Moving too quickly can lead to injury or damage.
- Stay Organized: Keep your workspace clean and well lit. Make sure pets and children are not nearby.
- Dry Conditions Only: Do not work with wet hands or in a damp area.
- Read the Manual: Check your user manual for any specific instructions related to safety or part replacement.
- Handle with Care: Remove and install parts gently to avoid breaking anything.
- Wear Gloves: Use insulated work gloves to protect your hands from sharp edges or debris.
- Be Cautious with Wiring: Avoid touching exposed wires. If you need to handle them, use non-conductive tools or wear insulating gloves.
- Take Photos: Before disconnecting any wires, take pictures or make notes so you can reconnect everything correctly.
- Use Tools Confidently: Do not attempt to test live voltage with a multimeter unless you are familiar with how to do it safely.
How to Test and Replace the Rear Cooktop Element on a Samsung Range
Follow these steps to test the functionality of the left or right rear cooktop element and replace it if necessary.
Testing the Left or Right Rear Cooktop Element
- Unplug the range from the power outlet.
- Open the oven door.
- Remove the screws at the top of the oven opening that hold the main cooktop in place.
- Lift the main cooktop up and flip it over to expose the heating elements.
- Set your multimeter to continuity mode.
- Place one probe on connector 1b (black wire).
- Place the other probe on connector 2b (yellow wire).
- Confirm there is no continuity with the element off.
- Set your multimeter to resistance mode (Ω).
- Place one probe on connector 2a (gray wire).
- Place the other probe on terminal A (blue wire terminal on the side of the element).
- Check for a resistance reading between 45 and 50 Ohms.
- Plug the range back into the power outlet.
- Turn the range on and set the element to operate.
- Set your multimeter to AC voltage mode.
- Place one probe on the 2a terminal (yellow wire).
- Place the other probe on terminal A (double violet wire).
- Check for a voltage reading of 240 volts AC.
- If resistance is within range but no voltage is detected, the element is likely faulty and should be replaced.
Replacing the Rear Cooktop Element
- Unplug the range from the power outlet.
- Disconnect the wiring from the faulty element.
- Remove the two screws that secure the bracket holding the element.
- Use a flathead screwdriver to release the clip holding the bracket.
- Remove the bracket.
- Lift out the faulty element and discard it.
- Place the new element on the glass cooktop.
- Reconnect the wiring to the new element.
- Reinstall the bracket and secure it with the two screws.
- Flip the glass cooktop back into place.
- Reinstall the screws under the cooktop that hold it in place.
- Replace the rear panel over the control board if it was removed.
- Plug the range back in and test the new element for proper function.
Tips for Working with Cooktop Parts
Cooktops are delicate and precision-built, so extra care is helpful when working with them. These tips may help the process go more smoothly:
- Lay a soft towel or mat on your work surface to protect the cooktop glass when setting it face down
- Keep screws and small parts in a labeled container to avoid losing them during reassembly
- Use a magnetic screwdriver if possible to help with hard-to-reach screws
- Clean the element area and the surrounding parts while the cooktop is open
- Avoid touching the heating surface with bare hands, as oil from your skin can damage the new element
- Double-check part numbers before ordering replacements to match your specific range model
- Watch for hidden clips or fasteners when removing panels
- Take note of how wires are routed so you can restore them to the same position
To Recap
In conclusion, replacing a faulty rear element on your Samsung range is a manageable task that can save you both time and money. By carefully following the steps outlined, you can troubleshoot the issue and swap the element without needing to call a repair technician. With a bit of patience, attention to detail, and the right tools, you can restore your cooktop to full working order. Just remember to prioritize safety throughout the process, and always double-check that you’re using the correct replacement parts. With this guide, you’ll be able to handle the repair like a pro.
