The flashing C5 error code on your GE dishwasher indicates frustration – your dishes are dirty and the washer isn’t working properly. This common issue occurs when the dishwasher fails to fill with enough water.
By carefully troubleshooting the potential causes, from low water pressure to faulty valves to leaks, you can identify the root problem and fix it.
This article provides an overview of the C5 error and guides you step-by-step through diagnosis and repair. Let’s get started resolving the issue and putting your dishwasher back in washing action!
Understanding the C5 Error Code
The C5 error code on a GE dishwasher indicates there is an issue with the water filling process during a wash cycle. Let’s break down what exactly this error means.
Definition of the C5 error code
The C5 error code alerts you that the dishwasher is not filling properly with water. It commonly appears about 2 minutes into the cycle, when the dishwasher should be finished filling.
Seeing a C5 error means:
- The dishwasher is not detecting the right water level at the expected time. This triggers the control board to shut off the cycle.
- There is likely an issue with the water supply, input parts, or detection system.
- The dishwasher cannot proceed with washing dishes until the error is fixed.
Insufficient water levels during the cycle
When the C5 error pops up, it means the dishwasher isn’t filling with enough water as programmed.
Here’s a quick overview of what should happen in normal operation:
- The cycle starts, and the water inlet valve opens to allow water to enter the tub.
- Water fills to the level needed for that specific wash cycle. This takes about 2 minutes.
- The pressure switch or water level sensor detects the right amount of water.
- The control board gets the signal that it’s OK to proceed.
With the C5 error, step 3 does not happen as expected. The water level is too low when the control board checks it. This causes the C5 code to display.
Potential Causes of the Error
Now that we know what the C5 error code means, let’s explore some possible reasons it could show up. Pinpointing the cause is key to fixing your GE dishwasher.
A. Low water pressure or partially closed water supply valve
One of the most common reasons for the C5 error is that water can’t flow properly into the dishwasher. Some examples include:
- Your home’s water pressure dropped lower than needed for the dishwasher to fill right.
- The water supply valve under the sink is partially closed or blocked.
- The water supply line is kinked or crimped.
- Sediment or minerals clogged the water inlet filter screen.
Do you notice low flow from other faucets? That’s a sign of an overall water pressure issue.
B. Malfunctioning water inlet valve
The water inlet valve controls water flow into the dishwasher. It’s an electrical part that opens and closes based on signals from the control board.
If this valve is broken, it could cause the C5 error in a few ways:
- It may not open at all, blocking all water from entering.
- It may open partially, restricting how much water gets in.
- It may not close properly once the tub is full.
Testing the valve is the best way to see if it’s the culprit. We’ll cover how a bit later.
C. Leaks in the dishwasher tub or door gasket
Leaks allow water to escape and prevent proper filling:
- Door gasket leaks – if the main door seal is damaged, water can seep out from the edges.
- Tub leaks – cracks or holes in the tub allow water to leak out before it reaches the right level.
Inspect the dishwasher carefully to find any leaks. You may see water on the floor under the unit.
D. Clogged pump inlet
Food debris getting clogged in the pump inlet screen can block water from properly circulating during the fill process. Make sure to clean out the pump filter regularly.
E. Leaky diverter valve
This small valve routes water to the right areas. If it leaks internally, it reduces overall water pressure.
Tools You’ll Need
When troubleshooting a C5 error code on your GE dishwasher, having the right tools on hand will make the process much smoother. Here’s a list of handy tools to have ready:
Screwdrivers
You’ll need both Phillips and flathead screwdrivers in various sizes. Some key things you may need to unscrew and access include:
- Control panels
- Kick plates
- Electrical components
- Valves
- Pump assemblies
Do you have a full screwdriver set ready? If not, it would be wise to invest in one.
Multimeter
How handy are you with electrical repairs? Testing dishwasher parts like the water inlet valve or heating element is useful. A multimeter lets you:
- Check for continuity
- Test ohms of resistance
- Detect voltage
Not sure how to use one? No worries! There are great YouTube tutorials on multimeter basics. It’s a handy device to have in your toolkit.
Safety Gear
Repairing appliances calls for caution, right? Be sure to grab:
- Gloves to protect your hands from sharp edges
- Goggles to shield your eyes
- A face mask to avoid breathing dust
Staying safe is priority #1, so take the time to suit up. No repair is urgent enough to risk injury.
Precautions Before Starting
Before you start troubleshooting and repairing your GE dishwasher’s C5 error code, there are some important precautions to take. Safety should always come first!
1. Unplug the Dishwasher or Turn Off the Circuit Breaker
Make sure to unplug the dishwasher from the electrical outlet or turn off the circuit breaker for the dishwasher before you begin any repairs. This prevents electric shock while you are working.
Do you know where your home’s electrical panel is located and which circuit breaker controls the dishwasher? If not, take a few minutes to locate it before starting. Safety first!
2. Ensure a Clean and Dry Work Area
It’s important to have a clean, dry area around the dishwasher to work. Remove any items stored near or under the dishwasher. Clean up any dirt, grease, or water on the floor. Make sure the area is free of clutter and slip hazards.
A clean workspace helps you avoid accidents and focus on the repairs. It also keeps small parts from getting lost!
3. Gather Safety Gear
Repairing appliances requires some safety precautions. Be sure to grab:
- Safety goggles to protect your eyes from debris
- Gloves to protect your hands from sharp edges
You may also want:
- A face mask if working in dusty areas
- Knee pads if you’ll be on the floor
Better safe than sorry! What safety gear do you think is most important?
4. Handle Electrical Components with Care
Some repairs will involve electrical parts like motors, valves, and control boards. Make sure to:
- Disconnect power before removing or replacing electrical components
- Don’t force connections – make sure plugs are properly aligned before connecting
- Check wires for damage before reconnecting
Be careful and thoughtful when dealing with anything electrical. Rushed repairs can lead to accidents!
5. Refer to the Dishwasher’s Manual
The final precaution is to read through the manufacturer’s manual for your GE dishwasher model before starting repairs. The manual will have:
- Exploded parts diagrams to help identify components
- Instructions for diagnosing issues
- Step-by-step repair procedures
- Warnings and cautions related to repairs
The manual is your best friend for DIY dishwasher repairs! Keep it handy or print relevant sections.
Step-by-Step Troubleshooting
Now, we’re ready to start identifying the cause of the C5 error code. Follow these troubleshooting steps in order to pinpoint the issue:
Check the Water Supply Valve
The first thing to check is the water supply valve. This valve is usually located under the sink and controls water flow to the dishwasher.
To check it:
- Locate the water supply valve under the sink.
- Make sure the valve is fully open.
- Check for kinks in the water supply line.
Are you getting a full stream of water through the valve? If not, the valve could be clogged or partially closed, reducing water flow.
Test Water Inlet Valve
The water inlet valve controls water flow into the dishwasher tub. Use a multimeter to test it:
- Unplug the dishwasher and disconnect the valve wires.
- Set a multimeter to test for continuity.
- Touch probes to valve wires. The multimeter should show continuity if the valve is okay.
- If there is no continuity, the valve is faulty and needs replacing.
Did you know multimeters let you test electrical parts without power? Cool!
Examine Dishwasher Tub and Door Gasket for Leaks
Check around the tub and door for leaks:
- Run a cycle and check for leaks around the door gasket.
- Inspect the dishwasher tub for cracks or holes.
Even small leaks can interfere with properly filling the tub with water.
See any leaks or damage? The gasket or tub may need replacing.
Clear Any Debris or Clogs from the Pump Inlet
A clogged pump inlet can trigger the C5 code, too. To inspect:
- Remove the lower access panel to expose the pump.
- Check for blockages at the pump inlet.
- Use a toothbrush to clean out any debris.
Did you find any food bits or broken glass blocking the inlet? Clear the clog!
Test Diverter Valve
The diverter valve routes water into the tub. Test it with a multimeter:
- Remove power and disconnect valve wires.
- Check for continuity when switching valve positions.
- No continuity means the valve is faulty.
Fixing the Identified Issues
Once you’ve diagnosed the cause of the C5 error code on your GE dishwasher, it’s time to fix the problem. Here are the steps for resolving some common issues:
Replacing a faulty water inlet valve
The water inlet valve controls the flow of water into the dishwasher. If it’s broken, water can’t enter the tub properly. Follow these steps to replace it:
- Locate the valve: The water inlet valve is usually at the bottom back of the dishwasher. Consult your manual for the exact location.
- Turn off water and power: Shut off the water supply to the valve and unplug the dishwasher.
- Disconnect and remove: Detach the water lines and electrical connector. Then, unscrew the valve and remove it.
- Install new valve: Screw in the new valve and reattach the lines and electrical plug.
- Restore water and power: Turn the water back on and plug in the dishwasher.
- Test with a cycle: Run a test cycle and check for leaks.
Repairing tub leaks or replacing the gasket
If water is leaking from the tub or door seal, inspect for damage and make repairs:
- Inspect the tub & gaskets: Check the dishwasher tub and door gasket for cracks, tears, or deterioration.
- Replace gasket if needed: If the gasket is damaged, remove the old one and install a replacement gasket.
- Assess & repair tub leaks: If the tub itself is leaking, you may need to apply sealant. Consult a technician for major tub repairs.
Clearing the pump inlet from debris
If the pump inlet or impeller is clogged, it can prevent proper water flow. To clear it:
- Access the pump: Remove the lower dishwasher access panel to get to the pump.
- Remove debris: Carefully pick out any glass, plastic, or food debris lodged in the pump inlet or impeller.
- Reassemble: Once clear, replace the access panel. Run an empty cycle to confirm that the water flows properly.
Replacing a faulty diverter valve
The diverter valve routes water to the spray arms. Follow these steps if it needs replacing:
- Locate the valve: It’s attached to the circulation pump outlet. Check your model’s manual.
- Get the right part: Match the replacement valve to your model.
- Remove old & install new: Detach the old valve and install the new one in the same place.
- Test the repair: Run a cycle and verify the spray arms work correctly.
Final Checks
You’re almost done! After completing repairs, follow these final steps to ensure the C5 error is fully resolved:
Inspect connections, components, and repairs
Give the dishwasher a thorough once-over to make sure everything is back together correctly. Check that:
- Electrical connectors are snapped in properly
- Water lines are tightly attached with no leaks
- Any repaired or replaced parts are securely installed
- No tools or debris were left behind
Restore power to the dishwasher
Plug the dishwasher back in or turn the circuit breaker back on.
Run a test cycle
Run a normal or heavy cycle to test all functions. Use empty dishes.
Observe water filling and draining
As the test cycle runs, check that:
- Water flows into the tub properly
- The tub fills to the normal level
- Water pumps out completely after the wash cycle
Check for leaks, noises, or performance issues
While test cycling, verify the following:
- No water leaks from connections or the tub
- No odd noises come from the pump or valves
- The spray arms rotate and distribute water normally
Revisit repairs if needed
If any problems occur during the test, turn off the dishwasher. Double-check the repairs and make adjustments.
Conclusion
You’ve made it to the end – congratulations! By now, you should have a good understanding of the C5 error code, what causes it, and how to fix it. Let’s do a quick recap:
- The C5 error code indicates that your dishwasher isn’t filling with enough water during the wash cycle.
- Potential causes include low water pressure, faulty inlet valves, leaks, clogged pumps, or bad diverter valves.
- By methodically troubleshooting each component, you can identify and repair the root cause.
- Replacing damaged parts like the inlet valve, tub, gasket, or diverter valve will resolve the C5 error.
- Adjusting the water supply, clearing debris/clogs, and sealing leaks also fixes low water flow.
Understanding causes of the C5 error equips you to address it. But prevention is ideal – maintain your dishwasher properly. When in doubt, consult a professional. With some diligence, you can keep your dishwasher running smoothly for years to come!
