A refrigerator door that will not close tightly can let cold air escape and lead to spoiled food. One common cause is a worn lower door hinge. This part helps keep the door aligned and allows it to close smoothly every time.
The lower fridge door hinge (part number AEH36821908) is located at the bottom of the left fresh-food door. It is spring-loaded to help the door open and close properly. Over time, it can wear out or break, which can cause the door to stop sealing as it should.
How to Identify a Worn Lower Door Hinge
Knowing when the hinge needs replacement can help you avoid larger issues with your fridge. Look for these signs:
- The door sags or appears misaligned when closed.
- There is a noticeable gap between the door and the fridge frame.
- The door requires extra force to close completely.
- The door swings open unexpectedly when left partially shut.
- Cold air escapes, making the fridge work harder and increasing energy use.
- Visible wear, rust, or bending on the hinge mechanism.
What You’ll Need
- Phillips screwdriver
- Flat-blade screwdriver
- Replacement lower fridge door hinge AEH36821908
Safety First
Before starting the repair, prepare your workspace and take steps to prevent injury. Appliance repairs involve sharp edges, heavy parts, and electrical components, so caution is essential.
- Unplug the refrigerator or switch off the circuit breaker before beginning.
- Turn off the water supply at the outlet to avoid leaks.
- Keep towels nearby for any remaining water in the system.
- Allow the appliance to cool down if it has been running recently.
- Work slowly and carefully to avoid mistakes and injuries.
- Use good lighting so every screw and part is visible.
- Clear the area of clutter, children, and pets.
- Consult the user manual for model-specific instructions.
- Handle parts gently to avoid damage.
- Wear insulated gloves to protect your hands from sharp edges.
- Avoid touching exposed wires and use insulated tools if necessary.
- Consider safety glasses or a dust mask if working in a dusty environment.
How to Replace an LG Lower Fridge Door Hinge
Here are the steps to remove the old lower hinge, install the new one, and reassemble the refrigerator.
Back Cover Removal
- Turn off the refrigerator and unplug it from the wall outlet.
- Locate the removable panel on the back of the fridge that covers the water line and electrical components.
- Remove the two Phillips screws holding the panel in place and set the cover aside.
Water Line and Top Hinge Cover
- Find the coiled water tubing running from the back of the fridge to the water dispenser.
- Press the release collar on the coupling and pull the tubing free, using a towel to catch drips.
- Locate the decorative top hinge cover on the left fresh food door.
- Remove the Phillips screw securing the cover and pry the cover off.
Door Wiring and Hinge Lever
- Disconnect the two wire harness plugs by pressing their locking tabs and pulling them apart.
- Use a flat-head screwdriver to pry open the hinge lever bracket on the top hinge.
Grounding Screw and Top Hinge Removal
- Remove the grounding screw that secures the two green wires to the top hinge.
- Insert a flat-head screwdriver into the seam around the top hinge cover and gently pry it off.
Door and Ice Bin Removal
- Open the left door and remove the ice bucket to reduce weight.
- Lift the door straight up and off the bottom hinge pin and set it aside.
Lower Hinge Removal
- Remove the three Phillips screws securing the black door stop bracket and the lower hinge at the base of the door.
- Remove the door stop piece.
- Pry the old lower hinge loose from its slot and remove it.
New Lower Hinge Installation
- Align the new lower hinge with the slot on the door base and press it firmly until it snaps into place.
Reassembly
- Reinstall the door stop bracket and secure it with the three Phillips screws.
- Lift the refrigerator door and lower it onto the center hinge pin.
- Position the top hinge so the inner tabs fit into the slots on the door’s left side and swing it into place.
- Reinstall the grounding screw to secure the two green wires to the hinge housing.
- Route the water tubing back through the opening at the top hinge and pull it through until it appears at the back.
- Plug both wire harness connectors back into place until they click.
- Press the decorative top hinge cover back on and secure it with the Phillips screw.
- Turn the water supply back on at the shut-off valve.
- Slide the water tubing back into the coupling until it clicks.
- Replace the rear protective cover and secure it with the two Phillips screws.
- Plug the refrigerator back in and restore power.
- Place the ice bin back into the door.
Maintenance Tips to Help the New Hinge Last Longer
Once the new hinge is installed, regular care can help it last for years.
- Wipe away spills or debris from the hinge area to prevent buildup.
- Avoid slamming the fridge door shut.
- Keep the fridge level so the door weight is evenly distributed.
- Check the hinge screws periodically and tighten if needed.
- Lubricate the hinge lightly with food-safe lubricant every 6–12 months.
- Inspect the door gasket regularly and replace it if cracked or torn.
- Limit heavy items stored on the door to reduce hinge strain.
Read More: 11 Ways to Increase the Efficiency of Your Refrigerator
Next Steps
A fresh lower door hinge can make a big difference in how your LG refrigerator works. A smooth-closing door keeps the cold air in, helps your food last longer, and saves on energy costs. With the right tools, a little preparation, and the right replacement part, this repair is something you can handle yourself. Taking the time to keep the hinge clean, check it regularly, and avoid putting too much strain on the door will help it stay in good shape for years. A well-working fridge door is one of those small fixes that can keep your kitchen running without a hitch.
