A leaking LG refrigerator can leave frustrating puddles on the kitchen floor. One common cause is a damaged reservoir water supply line. This tubing carries water from the filter to the reservoir, and over time, it can crack or split, leading to leaks.
The good news is that replacing it is a simple DIY project that usually takes less than 30 minutes. With basic tools and a replacement line, you can fix the problem and keep your refrigerator working properly.
How to Spot a Failing Reservoir Water Line
Sometimes leaks are obvious, but there are other signs that the water supply line is failing. Watch out for these issues:
- Water pooling underneath or behind the refrigerator
- Damp or warped flooring near the fridge
- Reduced water flow from the dispenser
- Ice maker producing small or hollow ice cubes
- Visible cracks or kinks in the tubing
- A musty or damp smell around the appliance
- Drips appearing at the back of the fridge after dispensing water
Catching these early can help you avoid water damage to floors or cabinets.
Tools and Parts You’ll Need
- Phillips screwdriver
- Flat-blade screwdriver
- Replacement reservoir water supply line (part number AJR56656503, make sure it matches your refrigerator model)
- Towels to catch water drips
Safety First
Before starting the repair, follow these safety guidelines:
- Unplug the refrigerator or switch off the circuit breaker before beginning work. This prevents the risk of electric shock.
- Allow the appliance time to cool down if it was running recently.
- Work carefully and avoid rushing to reduce the chance of injury or damage.
- Choose a well-lit, uncluttered space, and keep children and pets away.
- Keep your hands dry and make sure the work area is not wet.
- Refer to your refrigerator’s user manual for any model-specific details.
- Handle components gently to avoid breaking them.
- Wear insulated gloves to protect against sharp edges.
- Be careful when working near wires. Use non-conductive tools or insulated gloves if contact is necessary.
- Wear safety glasses or a dust mask when dealing with debris or chemicals.
How to Replace an LG Refrigerator Reservoir Water Supply Line
Follow these steps to safely remove the old water line and install a new one in your LG refrigerator.
Power and Water Shutoff
- Turn off the water supply valve to the refrigerator.
- Unplug the refrigerator or switch off the circuit breaker.
Back Panel Removal
- Locate the rear cover panel on the refrigerator.
- Remove the two Phillips screws securing the back cover and set the cover aside.
Disconnect Old Water Line
- Find the white plastic water tubing connected to the water line coupling.
- Depress the locking collar on the coupling and gently pull the tubing free, catching drips with a towel.
Hinge Cover Removal
- Locate the decorative hinge cover on the left fresh food door.
- Remove the Phillips screw and lift off the hinge cover.
Door Shelf Removal
- Open the fresh food door and remove the bottom shelf.
Reservoir Cover Removal
- Find the small access reservoir cover panel on the left wall.
- Remove the Phillips screw at the top of the reservoir cover.
- Use a flat screwdriver to release the locking pin and slide the cover off to the right.
Old Water Line Removal
- Place a towel under the reservoir.
- Depress the release collar on the water line and pull it free from the reservoir inlet.
- Feed the old water line out through the hinge space.
New Water Line Installation
- Feed the new tubing up through the hinge space from below.
- Push the tubing into the reservoir inlet until the first marked band is not visible.
Reservoir Cover Reinstallation
- Slide the reservoir cover back into place.
- Reinsert the locking pin and secure the top Phillips screw.
Door Shelf Reinstallation
- Replace the bottom door shelf by hooking it into the side brackets and pushing down.
Routing New Line
- Route the new tubing through the hinge space and secure it with clips to prevent kinks.
- At the back of the refrigerator, remove the end cap and insert the tubing into the opening.
Hinge Cover Reinstallation
- Reinstall the left hinge cover with its Phillips screw.
Final Steps
- Turn the water supply back on.
- Restore power to the refrigerator.
- Check for leaks around all tubing connections and tighten fittings if necessary.
Helpful Maintenance Tips
To extend the life of the new reservoir water supply line and keep your refrigerator in good shape, follow these practices:
- Wipe down the back of the fridge occasionally to check for moisture
- Replace the water filter on schedule as recommended by the manufacturer
- Keep the refrigerator slightly pulled out from the wall to reduce pressure on the tubing
- Inspect the water line every few months for small cracks or discoloration
- Use only manufacturer-approved replacement parts for repairs
- Avoid bending or twisting the tubing sharply during installation
- Clean the dispenser system periodically to prevent buildup
- Place a small water sensor on the floor near the fridge for early leak detection
What to Remember
A solid repair like this does more than stop a puddle on the floor. It keeps your refrigerator running smoothly and helps you avoid bigger problems down the road. Once you know the signs of a bad reservoir water line and how to swap it out, the fix is quick and straightforward. Keep an eye on your fridge with a little routine maintenance and you’ll save yourself time, money, and stress. Small steps like checking for moisture, replacing filters, and giving the back of your fridge a glance every so often can make a big difference. With the right part and a bit of care, your LG refrigerator stays reliable and ready for daily use.
