The speed control lever on your KitchenAid stand mixer allows you to adjust the speed settings for various mixing tasks. Over time, this lever may become worn out, making it difficult to change speeds or keep the lever in place. If your mixer’s speed control lever feels loose, wobbly, or unresponsive, it’s time for a replacement.
The good news? This is a straightforward repair that requires only a few tools and a bit of patience. Let’s get your mixer back to peak performance!
Signs Your Speed Control Lever Needs Replacement
Not sure if your mixer’s speed control lever is the issue? Here are some common signs that indicate it’s time for a replacement:
- The lever feels loose or wobbly and doesn’t stay in place.
- Difficulty adjusting the speed, with the mixer skipping or failing to change settings.
- The lever has visible cracks, breaks, or other signs of wear.
- The mixer unexpectedly changes speeds on its own or fails to start properly.
- The lever sticks in one position and won’t move smoothly.
What You’ll Need
- Replacement speed control lever (make sure it’s compatible with your specific mixer model)
- Planetary grease (WP4176597)
- Large and small flathead screwdrivers
- Large and small Phillips screwdrivers
- Large Phillips driver ratchet
- Hammer
- Punch
- Rubber mallet
- U-shaped holder (optional)
- Towels
Safety First
Safety is key when working on any appliance. Follow these guidelines to avoid accidents and mistakes:
- Always power off and unplug your appliance before performing any maintenance to prevent electric shock.
- If the mixer was recently used, give it time to cool down before starting repairs.
- Rushing can lead to mistakes or injuries. Take your time.
- A well-lit workspace will help you clearly see and access the parts you’re working on.
- Remove unnecessary items, and keep children and pets away from your workspace.
- Make sure your hands and work area are dry to prevent electrical hazards.
- Check for any specific instructions related to your appliance model.
- Avoid using excessive force to prevent damage.
- Insulated gloves will help protect your hands from sharp edges and debris.
- If you need to handle wires, use insulated gloves or non-conductive tools to minimize the risk of shock.
- Before disconnecting any wires or components, take photos or make notes to simplify reassembly.
How to Replace the Speed Control Lever on a KitchenAid Stand Mixer
Follow these steps to remove the old speed control lever and install a new one properly.
Preparation
- Unplug the mixer from the power outlet.
- Lift and turn the beater clockwise to release and remove it.
- Lift and remove the mixing bowl.
Removing the Planetary Gear
- Use a flathead screwdriver and a hammer to gently tap and remove the trim ring around the planetary gear.
- Position a punch on the groove pin and carefully tap it out with a hammer.
- Use a flathead screwdriver to pry down the planetary gear from its mounting.
- Work around the planetary gear to detach it and set it aside.
Removing the Rear Cover and Power Cord
- Unscrew the Phillips screw at the back of the mixer and carefully remove the cover.
- Use a small flathead screwdriver to disconnect the wires connected to the power cord.
- Detach the white wires first, then detach the black wires.
- Remove the ground wire screw with a Phillips screwdriver and lift the cord out of its strain relief.
Supporting and Disassembling the Base
- Position a U-shaped holder around the mixer head for support, or use towels to cushion and support the mixer.
- Carefully tip the mixer onto the support.
- If using a tilt-head mixer, remove the hinge pin with a punch.
- If using a bowl-lift model, use a ratchet for extra torque to remove the four large Phillips screws holding the base.
- Place towels underneath the mixer to catch any grease or debris.
- Use a flathead screwdriver to remove all visible screws from the lower half of the mixer.
- Carefully separate the housing halves to access the internal parts.
Cleaning and Inspecting Internal Components
- Inspect and clean the inside of the mixer.
- Replace grease or remove any metal shavings if needed.
- Note the position of any washers or locking mechanisms.
Replacing the Speed Control Lever
- Remove the old speed control lever by unscrewing it with a Phillips screwdriver.
- Align the new speed control lever with the internal bar.
- Make sure the speed control lever fits onto the pin properly.
- Hold the speed control lever in place while reattaching the screw and washer.
Reassembling the Mixer
- Align the center shaft and any mounting pins as you rejoin the housing halves.
- Replace and tighten all screws to hold the base together.
- Reattach the power cord wires.
- Place the rear cover back on and secure it with the screw.
Reassembling the Planetary Gear
- Align the planetary gear with the center shaft.
- Replace the groove pin so that it is flush and secure.
- Carefully fit the trim ring back onto the planetary gear.
- Use a rubber mallet if necessary to get a snug fit.
Final Steps
- Place the bowl onto the mixer so that it locks into place.
- Reattach the beater by aligning it with the shaft so that the locking mechanism engages.
- Plug in the mixer and test it for proper function.
Also Read: How To Clean And Maintain Your Stand Mixer
In Summary
A loose or stuck speed control lever can make using your KitchenAid mixer frustrating, but fixing it is easier than you might think. With a few basic tools and some careful steps, you can replace it yourself and get your mixer working smoothly again.
Ignoring this issue could lead to inconsistent mixing or even a mixer that stops working when you need it most. Taking the time to fix it now means you’ll have a reliable kitchen tool ready for your next baking project, whether it’s kneading dough, mixing batter, or whipping up something new.
