Kenmore washers that overfill or do not fill enough often have a faulty pressure switch. This part controls how much water enters the tub. When it fails, the washer may not respond to load size settings or may fill incorrectly. This repair is simple and can be done at home with basic tools.
Quick diagnosis table
Look at the pressure hose before blaming the switch, a blocked hose causes the same fill problems.
| Symptom detail | Likely cause | What to check | Fix or part |
|---|---|---|---|
| Washer keeps filling, will not stop | Failed pressure switch | Check water level against setting | Replace pressure switch |
| Fills below selected level | Blocked or cracked pressure hose | Inspect hose for buildup, cracks, leaks | Clear or replace hose, then switch |
| Load size setting has no effect | Electrical fault in switch | Change setting, listen for response | Replace pressure switch |
| Cycle pauses during fill | Loose or damaged wire connections | Check wire harness at switch | Reconnect harness, replace if damaged |
| Clicking from control panel area | Worn switch or moisture in console | Open console, inspect switch and wiring | Replace pressure switch |
| Water levels vary between loads | Detergent residue buildup in hose | Check hose for residue | Clean hose, use correct detergent |
Signs of a Faulty Pressure Switch
Recognizing early signs can help you fix the issue before it gets worse.
- Washer fills with too much water
- Washer does not fill to the selected level
- Water level does not match the setting on the control panel
- Cycle pauses or stops during the fill stage
- Washer keeps filling without stopping
- Washer does not start the wash cycle after filling
- Inconsistent water levels between loads
- Clicking sounds from the control panel area
- No response when changing load size settings
Common Causes of Pressure Switch Failure
Understanding what leads to failure can help you avoid the same issue later.
- Normal wear from repeated use over time
- Buildup inside the pressure hose that blocks airflow
- Cracks or leaks in the pressure hose
- Electrical faults within the switch
- Loose or damaged wire connections
- Exposure to moisture inside the control panel
- Sudden power surges affecting internal components
- Improper use of detergent leading to residue buildup
- Physical damage during previous repairs
What You Need
- Flat blade screwdriver
- Putty knife
- Replacement pressure switch
Safety Precautions
Working on a washer requires care and attention. These tips help reduce the risk of injury and damage.
- Turn off the washer and unplug it from the power source before starting
- Allow the machine to cool if it was recently used
- Work slowly and stay focused to avoid mistakes
- Use a well-lit workspace so all parts are easy to see
- Keep the area clear of clutter and away from children and pets
- Keep your hands dry when handling internal components
- Check the user manual for model-specific instructions
- Handle parts carefully to avoid breaking plastic clips or connectors
- Wear insulated gloves to protect your hands
- Avoid touching exposed wires directly
- Use safety glasses or a dust mask if debris is present
How to Replace a Kenmore Washer Pressure Switch
Follow these steps to remove and install the pressure switch in your washer safely and correctly.
Access the Console
- Locate the clips on the left and right sides of the console that secure it to the cabinet
- Slide a putty knife under the console about one inch from each end
- Push each clip toward the back while gently lifting and pulling the console forward
- Release one side first, then repeat on the other side
- Lift and flip the console over to access internal components
Remove the Old Pressure Switch
- Remove the load size control knob from the front of the console
- Flip the console back over to reach the pressure switch
- Disconnect the pressure hose from the switch carefully
- Remove the wire harness connected to the pressure switch
- Twist the pressure switch to release it from the console
- Install the new pressure switch into position
- Twist the new switch until it locks into place
Reassemble the Washer
- Reconnect the wire harness to the new pressure switch
- Attach the pressure hose back onto the switch
- Flip the console back into its original position
- Align the console tabs with the slots on the cabinet
- Press down firmly on the console until it locks back into place
How to Care for Your Washing Machine
Regular care helps prevent future issues and keeps your washer running smoothly.
- Run a cleaning cycle using washer cleaner, vinegar, or baking soda
- Check water supply lines for leaks, cracks, or buildup
- Wipe down the lid, panels, and hinges to remove dirt
- Clean the detergent dispenser to prevent clogs
- Use the correct type and amount of detergent
- Leave the lid open after use to reduce moisture buildup
- Match the load size to the amount of laundry
- Empty pockets before washing to avoid blockages
- Remove laundry right after the cycle to prevent odor buildup
Closing Thoughts
A faulty pressure switch can lead to frustrating fill problems, but it is a fix you can handle with a bit of time and care. Once the new switch is in place, your washer should respond better to settings and fill at the right level again.
Pay attention to early warning signs and keep up with simple maintenance to help your washer stay in good condition. Small steps like cleaning and checking parts now and then can help you avoid the same issue later.
This repair gives you more control over your appliance and helps you save money on service calls. With the right approach, your Kenmore washer can keep running smoothly for many more loads.
