Is your Samsung electric range acting up with uneven heating, inconsistent temperatures, or a triple element that’s not warming properly? If so, it may be time to replace the triple element. While this repair might seem intimidating at first, it’s a task you can handle yourself with the right tools and some patience. Doing it on your own can also help you save money and avoid a service call.
This guide will help you get started.
Common Signs of a Faulty Triple Element
It’s not always obvious when a triple element needs to be replaced. Here are several warning signs to watch for:
- One or more of the heating rings does not activate at all
- The element heats unevenly or fails to reach the right temperature
- Visible damage or discoloration on the surface of the element
- Burnt or melted areas around the element housing
- Food taking much longer to cook than usual
- Error codes or warning lights appearing on the control panel
- A clicking sound without any heating when the element is turned on
- Only one zone (inner or outer ring) is functioning while the others stay cold
What You’ll Need
- Replacement triple element (make sure it matches your specific Samsung range model)
- Phillips head screwdriver
- Flathead screwdriver
Safety Precautions
Before starting any repair, safety should come first. Keep the following tips in mind throughout the process:
- Turn off the power to the range by unplugging it or switching off the circuit breaker to eliminate the risk of electric shock
- Wait for the range to cool down completely if it was recently used
- Work slowly and carefully to reduce the risk of injury
- Use good lighting so you can clearly see what you’re doing
- Keep your workspace clean and free of anything that might get in the way. Keep children and pets out of the area
- Avoid working with wet hands, and make sure the surrounding area is dry
- Refer to your user manual for any model-specific instructions or warnings related to the replacement part
- Use care when removing or handling components to avoid damage
- Wear insulated work gloves to protect your hands from sharp metal edges or debris
- Do not touch exposed wires or terminals directly. Use non-conductive tools or wear insulating gloves
- Before disconnecting any wires or connections, take photos or write down how everything is connected. This will make it much easier to reassemble correctly
How to Replace a Triple Element in a Samsung Electric Range
Below are the steps to safely remove a faulty triple element and install a new one in your Samsung electric range.
Accessing the Cooktop
- Unplug the range from the power outlet or turn off the circuit breaker to disconnect power.
- Open the oven door to access the screws at the top of the oven opening.
- Remove the screws that hold the main cooktop in place.
- Go to the back of the range and remove the rear panel.
- Disconnect the wiring harness connected to the cooktop.
- Lift the main glass top and carefully flip it over to expose the underside.
Removing the Faulty Element
- Locate the metal bracket that holds the heating elements.
- Remove the two screws on each end of the bracket.
- Use a Phillips head screwdriver to gently pop loose the clip securing the bracket.
- Remove the bracket to free the heating elements.
- Disconnect the wiring from the faulty triple element.
- Remove the faulty triple element from the glass surface.
Installing the New Element
- Place the new triple element in the same position on the cooktop.
- Reconnect the wiring to the new element.
- Place the bracket back over the elements and secure it with the screws.
- Flip the cooktop back over and lower it into place.
Reassembly and Testing
- Reinstall the screws at the top of the oven opening to secure the cooktop.
- Reconnect the wiring harness at the back of the unit.
- Reinstall the rear panel.
- Plug the range back in or turn the circuit breaker back on.
- Turn on the new triple element to confirm it is functioning properly.
Also Read: How to replace the triple element on an electric Samsung range
The Bottom Line
Once your new triple element is in and working, you’re back in control of your cooking again. No more half-heated pans or slow dinners. Swapping out the part yourself might take a little time, but it’s a solid way to get your range working like new without calling in a technician. Just follow the steps, stay safe, and double-check your connections. A smooth repair like this one not only brings your kitchen back to life but gives you some confidence to tackle the next fix too.
