The diverter valve seal in your Bosch dishwasher ensures proper water flow for effective cleaning. Over time, wear or damage to this seal can compromise water circulation, resulting in subpar cleaning or leaks.
Replacing the diverter valve seal is a straightforward fix that can help maintain your dishwasher’s performance and prevent potential water damage.
Here’s a step-by-step guide to replace the diverter valve seal.
Signs Your Diverter Valve Seal Needs Replacement
Knowing when to replace the diverter valve seal can save time and prevent further damage. Here are some common signs that your seal may need attention:
- Water Leaks: Puddles of water around your dishwasher could indicate a worn or damaged seal.
- Poor Cleaning Performance: If dishes aren’t coming out clean, disrupted water flow might be the culprit.
- Unusual Noises: Strange sounds during the wash cycle, such as grinding or squealing, can point to an issue with the diverter valve or its seal.
- Error Codes: Some Bosch dishwasher models display error codes when there’s a problem with water circulation, which could be linked to the diverter valve seal.
Benefits of Regular Maintenance
Replacing the diverter valve seal is part of routine maintenance that helps keep your dishwasher running efficiently. Here’s why staying on top of maintenance matters:
- Prevents Leaks: A properly functioning seal minimizes the risk of water damage to your kitchen.
- Improves Cleaning Performance: Ensures water is distributed effectively throughout the dishwasher.
- Extends Appliance Lifespan: Reducing wear and tear on other components by maintaining optimal water flow.
- Saves on Repairs: Tackling small issues like a worn seal can prevent more costly repairs down the line.
Also read: 6 Easy Steps to Install a Dishwasher Drain Hose
Tools You’ll Need
- 5/8-inch wrench
- 5/16-inch nut driver
- Phillips screwdriver
- Flathead screwdriver
- 1/4-inch nut driver
Safety Precautions
When working on your dishwasher, prioritize safety with these essential tips:
- Disconnect Power: Always unplug the dishwasher or switch off the circuit breaker before starting any repair. This reduces the risk of electrical shock.
- Turn Off Water Supply: Shut off the water at the valve and have towels on hand to catch any residual water.
- Allow the Dishwasher to Cool: If recently used, let the appliance cool down to avoid burns or injury.
- Work in a Safe Environment: Choose a well-lit, clutter-free workspace, and keep children and pets away.
- Wear Protective Gear: Use insulated gloves to protect your hands from sharp edges or debris.
- Handle Parts Gently: Avoid using excessive force to prevent damage to components.
- Dry Hands and Work Area: Ensure everything is completely dry before starting repairs to avoid electrical hazards.
- Document Connections: Take photos or notes of wiring and connections before disassembly to make reassembly easier.
How to Replace the Diverter Valve Seal on a Bosch Dishwasher
Preparation
- Unplug the dishwasher from the power outlet.
- Shut off the water supply to the dishwasher, usually located under the sink.
- Place a towel under the dishwasher to catch any water during disconnections.
Disconnecting Hoses
- Locate the fill line connected to the hot water valve, turn off the water valve, and use a 5/8-inch wrench to loosen and unscrew the hose. Set the hose aside.
- Follow the drain hose to its connection point, often at the garbage disposal, and use a 5/16-inch nut driver to loosen the clamp. Remove the drain hose and set it aside.
Removing the Dishwasher
- Open the dishwasher door and remove the screws securing it to the countertop using a Phillips screwdriver.
- Lift the door slightly, pull the dishwasher out partially, and then fully remove it by pulling the frame.
- Fold up the insulation layer, lift it off, and set it aside.
Replacing the Diverter Valve Seal
- Locate the diverter valve at the bottom left of the dishwasher.
- Disconnect the wiring harness from the diverter valve by using a flathead screwdriver to lift the locking tab and pull it out.
- Loosen the crimped clamp securing the diverter valve using a flathead screwdriver, and remove the clamp.
- Rotate the diverter valve clockwise to unlock it from the tabs and pull it down to detach it from the sump.
- Remove the old diverter valve and seal.
- Slide a new clamp onto the rubber fitting and position it slightly higher than necessary. Tighten it with a 1/4-inch nut driver until snug.
- Place the new seal into the groove on the sump to secure it.
- Install the new diverter valve by lifting it into place and locking it in position.
- Reconnect the wiring harness to the diverter valve.
- Reconnect the circulation pump motor to the sump on the other side of the dishwasher and tighten the clamp securely using a nut driver.
Reassembling the Dishwasher
- Reinstall the insulation layer, ensuring it fits into the clips that secure it to the water-fill assembly.
- Slide the dishwasher back into position, starting halfway to ensure the lines underneath are not tangled, then push it fully into place.
- Reattach the drain hose and secure it with a clamp using a 5/16-inch nut driver.
- Reconnect the water line by hand-tightening it first and then using a 5/8-inch wrench to secure it further.
- Close the cabinet and dishwasher doors.
- Reinstall the screws to secure the dishwasher to the countertop using a Phillips screwdriver.
Testing
- Plug the dishwasher back into the power outlet and turn the water supply back on.
- Run a test cycle to verify the dishwasher is functioning properly.
Also read: Bosch dishwasher error code E22 troubleshooting guide
Whether you’re addressing leaks or restoring cleaning power, this guide equips you to handle the repair with confidence. With the right tools and a little patience, you can keep your dishwasher running like new—saving yourself time, money, and the hassle of larger repairs down the road.
